Gigabyte B550M DS3H AC 1.0/1.1/1.2/1.3 M/B Processor family AMD Padidinti

Gigabyte | B550M DS3H AC 1.0

110,39 €

B550M DS3H AC

4719331810962

Galimas pasirinkimas

 1..4 d.d.


Supported processor sockets: Socket AM4
Compatible processor series: 3rd Generation AMD Ryzen™ 3, AMD Ryzen 7 5th Gen, AMD Ryzen 9 5th Gen, 3rd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 9, AMD Ryzen 5 5th Gen
Processor manufacturer: AMD
Processor socket: Socket AM4
Compatible operating systems: Windows 10 64-bit
PC health monitoring: Voltage, CPU, Fan, Temperature
Motherboard chipset: AMD B550
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Windows operating systems supported: Windows 10
Cooling type: Passive
Power source type: ATX
Supported memory module capacities: 8GB, 32GB, 16GB, 4GB
Memory channels: Dual-channel
Supported memory clock speeds: 3333, 4000, 2400, 2667, 4400, 4600, 3200, 2933, 3600, 4733, 2133
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Number of memory slots: 4
Supported memory types: DDR4-SDRAM
Memory slots type: DIMM
Depth: 244 mm
Width: 244 mm
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n), 802.11a
Ethernet LAN: Yes
Wi-Fi: Yes
Bluetooth version: 4.2
WLAN controller model: Intel Dual Band Wireless-AC 3168
Ethernet interface type: Gigabit Ethernet
Power fan connector: Yes
Parallel connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
Number of SATA III connectors: 4
CPU fan connector: Yes
Front panel connector: Yes
ATX Power connector (24-pin): Yes
Number of Parallel ATA connectors: 1
USB 2.0 connectors: 1
Audio connector: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
RAID levels: 1, 10, 0
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, NVMe, SATA III
RAID support: Yes
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB connector type: USB Type-A
DVI-D ports quantity: 1
Microphone in: Yes
Headphone outputs: 1
PCI Express x16 slots: 1
PCI Express x4 slots: 1
PCI Express x1 slots: 1
