Lian Li RB0550B.B power supply unit 550 W 24-pin ATX ATX Black

Product colour: Black
Fan diameter: 13.5 cm
Number of fans: 1 fan(s)
Fan speed: 0 - 1300 RPM
Power protection features: Short circuit, Over voltage, Under voltage, Over current, Under temperature, Over power
AC input frequency: 50/60 Hz
Input current: 10 A
AC input voltage: 100 - 240 V
Combined power (+3.3V): 100 W
Max output current (+5Vsb): 3 A
Total power: 550 W
Power Factor Correction (PFC) type: Active
Max output current (+12V): 45.8 A
Combined power (+5V): 100 W
Combined power (+12V): 549.6 W
Combined power (-12V): 3.6 W
Efficiency: 85%
Max output current (+3.3V): 20 A
Max output current (-12V): 0.3 A
Max output current (+5V): 20 A
Combined power (+5Vsb): 15 W
Depth: 150 mm
Height: 150 mm
Width: 86 mm
Noise level: 33.2 dB
Purpose: PC
80 PLUS certification: 80 PLUS Bronze
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
Mean time between failures (MTBF): 100000 h
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
Floppy disk drive connector: Yes
Number of PATA power connectors: 3
EPS power connector (4+4 pin): Yes
PCI Express power connectors (6+2 pin): 4
Motherboard power cable length: 60 cm
Cabling type: Non-Modular
Motherboard power connector: 24-pin ATX
Floppy drive power connector: 1
CPU power cable length: 65 cm
CPU power connector (4+4 pin): Yes
