Cooler Master MPE-8501-AFAAG 850 W Padidinti

Cooler Master MPE-8501-AFAAG-EU power supply unit 850 W 24-pin ATX ATX Black

131,27 €

MPE-8501-AFAAG-EU

4719512106310

Galimas pasirinkimas

 pristatymas 5...7 d.d.


Fan speed: 0 - 1500 RPM
Product colour: Black
Number of fans: 1 fan(s)
Cooling type: Active
Fan diameter: 12 cm
Power Factor Correction (PFC) type: Active
Combined power (+5V): 100 W
Combined power (+3.3V): 100 W
Hold time: 16 ms
Max output current (+3.3V): 20 A
Combined power (+5Vsb): 15 W
Max output current (+5V): 20 A
Combined power (+12V): 849.6 W
Power Good signal delay range: 100 - 500 ms
Max output current (+5Vsb): 3 A
Combined power (-12V): 3.6 W
Max output current (+12V): 70.8 A
Max output current (-12V): 0.3 A
AC input voltage: 90 -264 V
AC input frequency: 47 - 63 Hz
Input current: 6 - 12 A
Power protection features: Under voltage, Over current, Short circuit, Over voltage, Overheating, Over power
Efficiency: 90%
Total power: 850 W
Operating temperature (T-T): 0 - 50 °C
Weight: 2.17 kg
Height: 86 mm
Depth: 160 mm
Width: 150 mm
Certification: ErP 2014 Lot 3, TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI
Power supply unit (PSU) form factor: ATX
Bearing technology: HDB
ATX version: 2.41
Mean time between failures (MTBF): 100000 h
Purpose: PC/Server
80 PLUS certification: 80 PLUS Gold
Noise level: 25.9 dB
Package weight: 2.57 kg
Package width: 194 mm
Package depth: 310 mm
Package height: 120 mm
SATA power cable length: 740, 500, 860 mm, 620
Motherboard power cable length: 61 cm
Cabling type: Modular
PCI Express power connectors (6+2 pin): 4
PCI Express power cable length: 67 cm
Motherboard power connector: 24-pin ATX
EPS power connector (4+4 pin): Yes
Number of SATA power connectors: 12
Peripheral (Molex) power cable length: 620, 860 mm, 740, 500
Peripheral (Molex) power connectors (4-pin): 4
EPS power connector (8-pin): Yes
Master (outer) case width: 325 mm
Master (outer) case length: 620 mm
Master (outer) case height: 220 mm
Products per pallet: 16 pc(s)
Products per master (outer) case: 5 pc(s)
Harmonized System (HS) code: 84733020
