MSI MAG A850GL PCIE5 WHITE power supply unit 850 W 20+4 pin ATX ATX

Cooling type: Active
Product colour: White
On/off switch: Yes
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Illumination: No
AC input frequency: 47 - 63 Hz
AC input voltage: 100 - 240 V
Power protection features: Over current, Short circuit, Over voltage, Overheating, Over power
Efficiency: 90%
Total power: 850 W
Combined power (+12V): 846 W
Max output current (+3.3V): 20 A
Combined power (+5V): 110 W
Maximum input current (@110V): 8 A
Maximum input current (@220V): 4 A
Combined power (+3.3V): 110 W
Max output current (+5Vsb): 2.5 A
Max output current (-12V): 0.3 A
Combined power (-12V): 3.6 W
Max output current (+12V): 70.5 A
Power Factor Correction (PFC) type: Active
Max output current (+5V): 20 A
Combined power (+5Vsb): 12.5 W
Depth: 140 mm
Width: 150 mm
Height: 86 mm
Purpose: PC
80 PLUS certification: 80 PLUS Gold
ATX version: 3.1
Power supply unit (PSU) form factor: ATX
Package type: Box
Peripheral (Molex) power connectors (4-pin): 4
ATX Power connector (24-pin): No
EPS power connector (8-pin): No
Cabling type: Fully-Modular
PCI Express connector: Yes
EPS power connector (4+4 pin): Yes
CPU power connector (4+4 pin): Yes
ATX power connector (20+4 pin): No
Motherboard power cable length: 60 cm
Motherboard power connector: 20+4 pin ATX
Number of SATA power connectors: 8
PCI Express power connectors (6+2 pin): 4
Harmonized System (HS) code: 84733020
Warnings: Do not open the case - risk of electric shock., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations., Avoid contact of the product with water or other liquids.
