Gigabyte PSU | GP-P650SS ICE GEU1 | 650 W | USED, REFURBISHED, MISSING MANUALS

Fan location: Top
Number of fans: 1 fan(s)
Cooling type: Active
Product colour: White
On/off switch: Yes
Fan diameter: 12 cm
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 100 W
Max output current (+5V): 20 A
Combined power (+5Vsb): 15 W
Combined power (+5V): 100 W
Combined power (+12V): 649.2 W
Max output current (+3.3V): 20 A
Max output current (-12V): 0.3 A
Max output current (+12V): 54.1 A
Max output current (+5Vsb): 3 A
Combined power (-12V): 3.6 W
Power Good signal delay range: 100 - 150 ms
Input current: 6.3 A
AC input voltage: 155-240 V
Power factor: 0.9
Power protection features: Overcharge, Short circuit, Over power, Under voltage
AC input frequency: 50/60 Hz
Total power: 650 W
Width: 140 mm
Depth: 150 mm
Weight: 2.23 kg
Height: 86 mm
Bearing technology: FDB
Mean time between failures (MTBF): 100000 h
ATX version: 3.0
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Silver
Purpose: PC
Package height: 117 mm
Package width: 254 mm
Package depth: 206 mm
Package type: Box
Package weight: 2.6 kg
SATA power cable length: 500 mm, 120
Cabling type: Non-Modular
CPU power cable length: 60 cm
Peripheral (Molex) power cable length: 500 mm, 120
ATX power connector (20+4 pin): Yes
CPU power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
CPU P4 connector (4-pin): 1
Number of SATA power connectors: 5
PCI Express power connectors (6+2 pin): 2
PCI Express power cable length: 65 cm
Motherboard power cable length: 60 cm
Floppy disk drive connector: Yes
Peripheral (Molex) power connectors (4-pin): 2
Warranty period: 3 year(s)
