Nauja Cooler Master Elite NEX 230V 700 power supply unit 700 W 24-pin ATX ATX Black Padidinti

Cooler Master Elite NEX 230V 700 power supply unit 700 W 24-pin ATX ATX Black

64,31 €

4719512128374

Galimas pasirinkimas

 pristatymas 11...13 d.d.


Sustainability compliance: Yes
Product colour: Black
Number of fans: 1 fan(s)
Cooling type: Active
Fan diameter: 12 cm
Max output current (+12V): 54 A
Max output current (+5V): 17 A
Max output current (+5Vsb): 2.5 A
Power Good signal delay range: 100 - 500 ms
Max output current (-12V): 0.3 A
Power protection features: Short circuit, Over voltage, Under voltage, Over power, Overheating
Total power: 700 W
Input current: 5 A
Combined power (+3.3V): 110 W
Max output current (+3.3V): 19 A
Hold time: 10 ms
Combined power (-12V): 3.6 W
Efficiency: 75%
AC input frequency: 47 - 63 Hz
Combined power (+5Vsb): 12.5 W
Combined power (+5V): 110 W
AC input voltage: 200 - 240 V
Power Factor Correction (PFC) type: Active
Combined power (+12V): 648 W
Operating temperature (T-T): 0 - 40 °C
Depth: 140 mm
Height: 86 mm
Weight: 1.45 kg
Width: 150 mm
ATX version: 2.41
Mean time between failures (MTBF): 100000 h
80 PLUS certification: No
Purpose: PC
Bearing technology: Sleeve
Power supply unit (PSU) form factor: ATX
Package height: 95 mm
Package depth: 245 mm
Package width: 190 mm
Package weight: 1.82 kg
Certification: ErP 2014 Lot 3
Compliance certificates: UKCA, CE
Number of SATA power connectors: 5
SATA power cable length: 400, 700 mm, 550
Peripheral (Molex) power cable length: 700 mm, 400, 550
Motherboard power connector: 24-pin ATX
PCI Express power cable length: 62 cm
Motherboard power cable length: 55 cm
EPS power connector (4+4 pin): Yes
Peripheral (Molex) power connectors (4-pin): 3
PCI Express power connectors (6+2 pin): 2
Cabling type: Non-Modular
EPS power connector (8-pin): Yes
EPS cable length: 67 cm
Master (outer) case width: 260 mm
Master (outer) cases per pallet: 64 pc(s)
Master (outer) case height: 220 mm
Products per master (outer) case: 5 pc(s)
Master (outer) case length: 503 mm
