IP Camera DS-2CD1023G2-LIU(2.8mm)

Lens mount interface: M12
Housing material: Metal, Plastic
Form factor: Bullet
International Protection (IP) code: IP67
Mounting type: Ceiling/wall
Product colour: White
DC output voltage: 12
Power source type: DC, PoE
Digital watermark: Yes
Intelligent Video Surveillance (IVS) system features: Vehicle detection, Human detection
Password reset via email: Yes
Mirror: Yes
Password protection: Yes
Video motion detection: Yes
Heartbeat: Yes
Active tampering alarm: Yes
Digest authentication: Yes
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Width: 66 mm
Depth: 170.8 mm
Height: 69.1 mm
Weight: 265 g
Wi-Fi: No
Live view: Yes
Ethernet LAN: Yes
User access level: Administrator, Operator, User
Number of simultaneous live view channels: 6 channels
Number of users: 32 user(s)
Supported network protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
Networking standards: IEEE 802.3af
Bluetooth: No
Languages support: English, Ukrainian
Type: IP security camera
Day/night mode: Yes
Number of languages: 2
Infrared (IR) cut-off filter: Yes
Alarm input/output: Yes
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Package weight: 495 g
Package width: 121 mm
Package height: 118 mm
Package depth: 216 mm
Number of cameras: 1
Voice codecs: MP2L2, G.726, G.711ulaw, G.711alaw, G.722.1, AAC
Signal-to-Noise Ratio (SNR): 52 dB
Built-in microphone: Yes
Built-in HDD: No
Card reader integrated: No
Ethernet LAN (RJ-45) ports: 1
Camera shutter speed: 1/3 - 1/100000 s
Angle of rotation: 360°
Lens viewing angle, vertical: 56°
Lens viewing angle, diagonal: 121°
Minimum illumination: 0 lx
Number of Privacy masking areas: 4
Lens viewing angle, horizontal: 103°
Pan range: 0 - 360°
Tilt angle range: 0 - 90°
Progressive scan: Yes
Sensor type: CMOS
Number of sensors: 1
Optical sensor size: 25.4 / 2.9 mm (1 / 2.9")
Noise reduction: Yes
Frame rate: 30 fps
Supported graphics resolutions: 1280 x 720 (HD 720), 640 x 360, 640 x 480 (VGA), 1920 x 1080 (HD 1080)
Video compression formats: M-JPEG, H.264, H.265+, H.264+, H.265
Digital Wide Dynamic Range (DWDR): Yes
Image quality adjustment: Saturation, Contrast, Brightness, Sharpness
Region of Interest (ROI) encoding: Yes
Back Light Compensation (BLC): Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels: 2 MP
Highlight Compensation (HLC): Yes
Bit rate: 32 Kbps - 8 Mbps
Privacy masking: Yes
Noise reduction technology: 3D noise reduction
Maximum resolution: 1920 x 1080 pixels
LED type: IR
Night vision distance: 30 m
Infra-red wavelength: 850 nm
Night vision: Yes
Recognize distance: 9 m
Fixed focal length: 2.8 mm
Maximum aperture number: 1.6
Number of lenses: 1
Observe distance: 18 m
Identify distance: 4 m
Detect distance: 45 m
Sustainability compliance: Yes
Compliance certificates: REACH, WEEE, RoHS
