TP-LINK SafeStream Gigabit Multi-WAN VPN Router

Certification: CE, FCC, RoHS
Windows operating systems supported: Windows 8, Windows 7, Windows NT, Windows 98SE, Windows 8.1, Windows Vista, Windows XP, Windows 10, Windows 2000
Internal memory type: DRAM
Internal memory: 256 MB
Mac operating systems supported: MacOS
Flash memory: 128 MB
Linux operating systems supported: Yes
Product colour: Black
Rack capacity: 1U
LED indicators: Activity, System, USB, WAN, LAN
Rack mounting: Yes
Flash memory: 16 MB
Embedded DRAM (eDRAM) memory: 128 MB
Power source type: AC
AC input frequency: 50 - 60 Hz
AC input voltage: 120 - 240 V
Power consumption (typical): 7.94 W
NAT functionality: • One-to-One NAT• Multi-Net NAT• Virtual Server• Port Triggering• NAT-DMZ• FTP/H.323/SIP/IPSec/PPTP ALG, UPnP
VPN support: • 20 IPsec VPN Tunnels• LAN-to-LAN, Client-to-LAN• Main, Aggressive Negotiation Mode• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm• IKEv1/v2• MD5, SHA1 Authentication Algorithm• NAT Traversal (NAT-T)• Dead Peer Detection (DPD)• Perfect Forward Secrecy (PFS)• PPTP VPN Server• 10 PPTP VPN Clients• 16 Tunnels• PPTP with MPPE Encryption• L2TP VPN Server• 10 L2TP VPN Clients• 16 Tunnels• L2TP over IPSec• OpenVPN Server• 10 OpenVPN Clients• 16 OpenVPN Tunnels
Network address translation (NAT): Yes
Security algorithms: 256-bit AES, 3DES, MD5, DES, 128-bit AES, SHA-1, 192-bit AES
VPN tunnels quantity: 20
DoS attack prevention: Yes
Firewall: Yes
ARP attack prevention: Yes
System event log: Yes
URL filtering: Yes
Authentication method: SHA-1, MD5
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Web-based management: Yes
Reset button: Yes
Universal Plug and Play (UPnP): Yes
Height: 25 mm
Depth: 101 mm
Width: 158 mm
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Networking standards: IEEE 802.3u, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab
Ethernet interface type: Gigabit Ethernet
Cabling technology: 10/100/1000Base-T(X)
Concurrent connections: 150000
VLAN support: Yes
Policy-based routing: Yes
Traffic control: Yes
Package weight: 650 g
Package width: 190 mm
Package depth: 254 mm
Package height: 60 mm
Quick start guide: Yes
Cables included: AC
Manual: Yes
Quick installation guide: Yes
Compliance certificates: RoHS
Supported protocols: IPsec/PPTP/L2TP
DHCP client: Yes
Routing protocols: RIP-1, RIP-2
Supported network protocols: TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP
DHCP server: Yes
Management protocols: Telnet
DMZ support: Yes
Ethernet LAN (RJ-45) ports: 5
USB ports quantity: 1
3G/4G USB modem compatibility: No
DSL WAN: No
Ethernet WAN: Yes
SIM card slot: No
Warnings: The product may emit radio waves that may interfere with other electronic devices., Avoid contact with liquids as this may cause electric shock., Do not open the appliance housing - risk of electric shock.
