ARCHER C6

Product colour: White
LED indicators: LAN, Power, WLAN
On/off switch: Yes
Indication light: Yes
Product type: Tabletop router
Power source type: AC
Output current: 1 A
Output voltage: 12 V
Stateful Packet Inspection (SPI): Yes
Security algorithms: WPA-PSK, WPA2-PSK, WPA, 64-bit WEP, WPA2, 128-bit WEP
Filtering: Yes
MAC address filtering: Yes
DMZ support: Yes
DoS attack prevention: Yes
Guest access: Yes
Firewall: Yes
IP address filtering: Yes
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 40 °C
Reset button: Yes
WPS push button: Yes
Height: 32 mm
Width: 215 mm
Depth: 117 mm
VPN support: PPTP, L2TP, IPSec
Receiver sensitivity: 5GHz: 11a 54M: -76dBm 11ac VHT20 MCS8: -70dBm 11ac VHT40 MCS9: -65.5dBm 11ac VHT80 MCS9: -61.5dBm 2.4G: 11g 54M: -76dBm 11n HT20 MCS7: -74dBm 11n HT40 MCS7: -71dBm
Ethernet LAN data rates: 10, 100
Networking standards: IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11a
Ethernet LAN interface type: Fast Ethernet
Port forwarding: Yes
VPN Passthrough: Yes
Ethernet LAN: Yes
Cabling technology: 10/100Base-T(X)
Windows operating systems supported: Windows Vista Home Basic, Windows Vista Home Basic x64, Windows 8 x64, Windows Vista Business x64, Windows Vista Business, Windows 8.1, Windows Vista Ultimate, Windows Vista Home Premium x64, Windows 8 Pro x64, Windows 8.1 Pro, Windows Vista Enterprise, Windows 8.1 Enterprise, Windows Vista Enterprise x64, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 8.1 x64, Windows Vista Ultimate x64, Windows 10 Education x64, Windows XP Home x64, Windows 10 Education, Windows XP Professional, Windows Vista Home Premium, Windows XP Home, Windows XP Professional x64, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 Home x64, Windows 8, Windows 7 Ultimate x64, Windows 7 Home Basic, Windows 7 Ultimate, Windows 7 Professional x64, Windows 10 Pro x64, Windows 8 Enterprise, Windows 10 Home, Windows 7 Starter x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 7 Home Basic x64, Windows 7 Professional
Linux operating systems supported: Yes
Mac operating systems supported: MacOS
Mac compatibility: Yes
Package weight: 870 g
Package type: Box
Package width: 350 mm
Package height: 82 mm
Package depth: 240 mm
AC adapter included: Yes
Quick start guide: Yes
Cables included: LAN (RJ-45)
Manual: Yes
Quick installation guide: Yes
WLAN data transfer rate (first band): 450 Mbit/s
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (second band): 867 Mbit/s
Wi-Fi standards: 802.11a, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n), 802.11g
WLAN data transfer rate (max): 867 Mbit/s
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
DHCP client: Yes
VoIP protocols: IPv4, IPv6
DHCP server: Yes
Universal Plug and Play (UPnP): Yes
Ethernet LAN (RJ-45) ports: 5
DC-in jack: Yes
Memory card slot(s): No
USB port: No
Transmit power: CE: <20dBm(2.4GHz), <23dBm(5GHz)
Antennas quantity: 5
Antenna design: External
DSL WAN: No
WAN connection type: RJ-45
3G/4G USB modem compatibility: No
SIM card slot: No
Ethernet WAN: Yes
Maximum data transfer rate: 1 Mbit/s
Harmonized System (HS) code: 85176990
3G: No
4G: No
