Asus | TUF GAMING A620M-PLUS | Processor family AMD | Processor socket AM5 | DDR5 DIMM | Memory slots 4 | Supported hard disk dr

Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series
Parallel processing technology support: Not supported
Cooling type: Passive
Windows operating systems supported: Windows 11, Windows 10
Component for: PC
Motherboard chipset family: AMD
Power source type: ATX
Motherboard chipset: AMD A620
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Memory slots type: DIMM
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Supported memory clock speed (max): 6400 MHz
Supported memory clock speeds: 5200, 6400, 6200, 5000, 5600, 4800, 5800, 5400, 6000
Maximum internal memory: 128 GB
ECC сompatibility: ECC & Non-ECC
Width: 244 mm
Depth: 244 mm
Wi-Fi: No
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
12V power connector: Yes
EPS power connector (8-pin): Yes
RGB LED pin header: Yes
Number of chassis fan connectors: 2
ATX Power connector (24-pin): Yes
Number of COM connectors: 1
CPU fan connector: Yes
S/PDIF out connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
Front panel audio connector: Yes
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Package height: 67.5 mm
Package depth: 275 mm
Package weight: 850 g
Package width: 275 mm
Cables included: SATA
User guide: Yes
Number of HDDs supported: 4
RAID levels: 10, 0, 1
Number of storage drives supported: 6
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI version: 2.1
Line-in: Yes
PS/2 ports quantity: 1
Headphone outputs: 1
USB 2.0 ports quantity: 4
DisplayPort version: 1.4
DisplayPorts quantity: 2
Ethernet LAN (RJ-45) ports: 1
PCI Express x1 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
Back-to-BIOS button: Yes
