Asus | PRIME Z790-P WIFI | Processor family Intel | Processor socket LGA1700 | DDR5 | Supported hard disk drive interfaces SATA,

Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®
Processor socket: LGA 1700
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Parallel processing technology support: Not supported
On-board graphics card: No
Product colour: Black, Aluminium
Audio output channels: 7.1 channels
Motherboard chipset: Intel Z790
Motherboard form factor: ATX
Motherboard chipset family: Intel
Power source type: ATX
Windows operating systems supported: Windows 10 x64, Windows 11
Supported memory clock speeds: 5600 MHz, 7200, 6600, 6400, 5000, 5200, 6200, 6000, 4800, 5800, 5400, 7000, 6800
ECC сompatibility: Non-ECC
Unbuffered memory: Yes
Maximum internal memory: 128 GB
Supported memory clock speed (max): 7200 MHz
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Width: 305 mm
Height: 40 mm
Depth: 234 mm
Bluetooth: Yes
Bluetooth version: 5.2
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), 802.11g, 802.11b
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
S/PDIF out connector: Yes
Front panel audio connector: Yes
Thunderbolt headers: 1
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
12V power connector: Yes
Number of COM connectors: 1
CPU fan connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
TPM connector: Yes
Peripheral (Molex) power connectors (4-pin): 1
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 3
BIOS type: UEFI AMI
Clear CMOS button: Yes
Package weight: 1.68 kg
Package width: 338 mm
Package depth: 273 mm
Package height: 68 mm
Drivers included: Yes
Cables included: SATA
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
RAID levels: 0, 1, 5, 10
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Headphone outputs: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
PS/2 ports quantity: 1
WiFi-AP antenna jack: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Microphone in: Yes
HDMI ports quantity: 1
Line-in: Yes
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 3
Number of M.2 (M) slots: 3
Weight: 1.03 kg
Warnings: Avoid direct contact with electronics to prevent electrostatic damage., Before starting any maintenance or installation, disconnect the product from the power supply., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
