Mainboard ASUS TUF GAMING B760-PLUS WIFI Padidinti

Mainboard ASUS TUF GAMING B760-PLUS WIFI

163,37 €

4711387095119

Galimas pasirinkimas

 pristatymas 5...7 d.d.


Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i3
Processor manufacturer: Intel
Maximum number of SMP processors: 1
Parallel processing technology support: Not supported
Windows operating systems supported: Windows 11, Windows 10
Cooling type: Passive
Audio output channels: 7.1 channels
Motherboard chipset: Intel B760
Motherboard form factor: ATX
Power source type: ATX
Motherboard chipset family: Intel
Number of memory slots: 4
Memory channels: Dual-channel
Supported memory clock speed (max): 5066 MHz
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Unbuffered memory: Yes
Maximum internal memory: 128 GB
Depth: 244 mm
Width: 305 mm
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth version: 5.2
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11g
Ethernet LAN: Yes
Bluetooth: Yes
Number of COM connectors: 1
12V power connector: Yes
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 3
CPU fan connector: Yes
TPM connector: Yes
Front panel connector: Yes
Peripheral (Molex) power connectors (4-pin): 1
RGB LED pin header: Yes
Front panel audio connector: Yes
S/PDIF out connector: Yes
Thunderbolt headers: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
BIOS type: UEFI AMI
Package height: 53 mm
Package weight: 1.16 kg
Package depth: 266 mm
Package width: 328 mm
Cables included: SATA
RAID levels: 10, 5, 1, 0
Number of storage drives supported: 7
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 3.0, PCI Express 5.0, SATA III
RAID support: Yes
VGA (D-Sub) ports quantity: 1
Headphone outputs: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 2x2 Type-C ports quantity: 1
USB 2.0 ports quantity: 2
Line-in: Yes
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
DisplayPort version: 1.4
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
