Intel Pentium Gold G7400 processor 6 MB Smart Cache Box

OpenCL version: 3.0
OpenGL support: Yes
Launch date: Q1'22
Status: Launched
Bus type: DMI4
Processor cores: 2
Processor socket: LGA 1700
Processor cache type: Smart Cache
Processor model: G7400
Processor manufacturer: Intel
Processor family: Intel® Pentium® Gold
Processor operating modes: 64-bit
Processor cache: 6 MB
Processor ARK ID: 219435
Processor codename: Alder Lake
Processor threads: 4
Stepping: H0
Processor base frequency: 3.7 GHz
Maximum number of DMI lanes: 8
Performance-core base frequency: 3.7 GHz
Memory bandwidth supported by processor (max): 76.8 GB/s
Processor base power: 46 W
Performance cores: 2
Number of execution units: 16
Discrete graphics card model: Not available
On-board graphics card base frequency: 300 MHz
On-board graphics card DirectX version: 12.0
On-board graphics card model: Intel UHD Graphics 710
On-board graphics card: Yes
Discrete graphics card: No
On-board graphics card outputs supported: HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, DisplayPort 1.4, Embedded DisplayPort (eDP)
On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 5120 x 3200 pixels
On-board graphics card dynamic frequency (max): 1.35 MHz
Number of displays supported (on-board graphics): 4
On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz
On-board graphics card ID: 0x4693
On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics card OpenGL version: 4.5
Multi-Format Codec Engines: 1
Maximum number of PCI Express lanes: 20
PCI Express slots version: 4.0, 5.0
Execute Disable Bit: Yes
CPU configuration (max): 1
Embedded options available: Yes
PCI Express configurations: 1x16+1x4, 2x8+1x4
Thermal Monitoring Technologies: Yes
Supported instruction sets: SSE4.2, AVX 2.0, SSE4.1
Idle States: Yes
Thermal solution specification: PCG 2020C
Commodity Classification Automated Tracking System (CCATS): G167599
Export Control Classification Number (ECCN): 5A992.C
Scalability: 1S
Market segment: Desktop
Use conditions: PC/Client/Tablet
Direct Media Interface (DMI) Revision: 4.0
Memory channels: Dual-channel
Memory bandwidth (max): 76.8 GB/s
Maximum internal memory supported by processor: 128 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Tjunction: 100 °C
Processor package size: 45 x 37.5 mm
Intel® Quick Sync Video Technology: Yes
Intel Enhanced Halt State: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Secure Key: Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Intel 64: Yes
Enhanced Intel SpeedStep Technology: Yes
Intel® Optane™ Memory Ready: Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Turbo Boost Technology: No
Intel® Clear Video HD Technology (Intel® CVT HD): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® OS Guard: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel Turbo Boost Max Technology 3.0: No
Intel® Volume Management Device (VMD): Yes
Mode-based Execute Control (MBE): Yes
Intel® Boot Guard: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Thread Director: No
Intel® Speed Shift Technology: Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
Intel® Standard Manageability (ISM): Yes
Maximum internal memory: 128 GB
L2 cache: 2560 KB
Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
Harmonized System (HS) code: 85423119
Warnings: Avoid contact with liquids., Do not dismantle the appliance., Avoid exposure to high temperatures and direct sunlight.
