TP-LINK | Switch | TL-SG1016PE | Web Managed | Desktop

LED indicators: Yes
Rack mounting: Yes
Product colour: Black
Number of fans: 1 fan(s)
Stackable: No
Power supply included: Yes
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power consumption (max): 124.4 W
Loop protection: Yes
Static port security: Yes
IGMP snooping: Yes
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Quality of Service (QoS) support: Yes
Switch type: Managed
Web-based management: Yes
Switch layer: L2
Height: 44 mm
Width: 294 mm
Depth: 180 mm
Full duplex: Yes
Cable types supported: Cat6, Cat4, Cat5, Cat5e, Cat3
10G support: No
Port mirroring: Yes
Auto MDI/MDI-X: Yes
Rate limiting: Yes
Number of VLANs: 4000
Flow control support: Yes
Auto-negotiation: Yes
Link aggregation: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3af, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1p, IEEE 802.3ad
Broadcast storm control: Yes
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-T, 10BASE-T
Virtual LAN features: Port-based VLAN, Tagged VLAN
VLAN support: Yes
Cables included: AC
Rack mount kit: Yes
Gigabit Ethernet (copper) ports quantity: 16
Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Harmonized System (HS) code: 85176990
Number of queues: 4
Throughput: 23.8 Mpps
Jumbo frames support: Yes
MAC address table: 8000 entries
Switching capacity: 32 Gbit/s
Store-and-forward: Yes
Jumbo frames: 10000
Total Power over Ethernet (PoE) budget: 150 W
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 8
Power over Ethernet (PoE) power per port: 30 W
Warnings: Do not open the case or try to repair it yourself., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Ensure the unit is adequately ventilated during operation.
