TP-LINK | JetStream 28-Port Gigabit Smart Switch | TL-SG2428P | Web Managed | Rackmountable | SFP ports quantity 4 | PoE+ ports

Number of fans: 2 fan(s)
Form factor: 1U
Rack mounting: Yes
Product colour: Black
Power supply included: Yes
Power consumption (max): 306.9 W
AC input voltage: 100 - 240 V
Power source: AC
AC input frequency: 50/60 Hz
Security algorithms: SSH, SSL/TLS, HTTPS, SNMPv2, SNMP, SNMPv3, SSH-2
Access Control List (ACL): Yes
DHCP features: DHCP server, DHCP client, DHCP relay, DHCPv6 client, DHCP snooping
IGMP snooping: Yes
SSH/SSL support: Yes
Authentication type: RADIUS
IP-MAC-Port binding: Yes
BPDU filtering/protection: Yes
Queue scheduling algorithms: SP, WRR+SP, Weighted Round Robin (WRR)
Operating temperature (T-T): 0 - 50 °C
Heat dissipation: 1047.3 BTU/h
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Switch layer: L2/L2+
System event log: Yes
MIB support: Y
Switch type: Managed
Quality of Service (QoS) support: Yes
ARP inspection: Yes
Web-based management: Yes
Height: 44 mm
Width: 440 mm
Depth: 220 mm
Networking standards: IEEE 802.3x, IEEE 802.1x, IEEE 802.1p, IEEE 802.3i, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.3af, IEEE 802.3az, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3at, IEEE 802.1Q
Port mirroring: Yes
Broadcast storm control: Yes
Rate limiting: Yes
VLAN support: Yes
Copper ethernet cabling technology: 1000BASE-T, 10BASE-T
Flow control support: Yes
10G support: No
Number of VLANs: 4000
Spanning tree protocol: Yes
Link aggregation: Yes
Cable types supported: Cat5, Cat5e, Cat3, Cat4
Virtual LAN features: MAC address-based VLAN, Protocol-based VLAN, Voice VLAN
Firmware upgradeable: Yes
Package height: 100 mm
Package width: 336 mm
Package weight: 3.98 kg
Package depth: 528 mm
Cables included: AC
Rack mount kit: Yes
User guide: Yes
Management protocols: SNMPv1/v2c/v3, SNTP
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 4
Gigabit Ethernet (copper) ports quantity: 24
Harmonized System (HS) code: 85176990
Packet buffer memory: 4.1 MB
MAC address table: 8000 entries
Switching capacity: 56 Gbit/s
Jumbo frames support: Yes
Jumbo frames: 9000
Forwarding rate: 41.7 Mpps
Number of queues: 8
Power over Ethernet plus (PoE+) ports quantity: 24
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 250 W
Multicast support: Yes
Warnings: The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Do not open the case or try to repair it yourself., Ensure the unit is adequately ventilated during operation.
Fiber ethernet cabling technology: 1000BASE-X
