Cudy GS2024S2 network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Black

LED indicators: Link, Activity, Power, System
Product colour: Black
Rack mounting: Yes
Stackable: Yes
Form factor: 1U
AC input voltage: 90 - 260 V
AC input frequency: 50/60 Hz
Power supply included: Yes
Power source: AC
Authentication: Port-based authentication
IGMP snooping: Yes
IP-MAC-Port binding: Yes
Authentication type: AAA, TACACS+
SSH/SSL support: Yes
DHCP features: DHCP server, DHCP Option 82, DHCP snooping
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -10 - 50 °C
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2/L3
System event log: Yes
Traffic classification: Yes
Switch type: Managed
Depth: 204 mm
Height: 44 mm
Width: 440 mm
Weight: 2.45 kg
Ethernet LAN data rates: 10,100,1000 Mbit/s
Networking standards: IEEE 802.1Qav, IEEE 802.11j, IEEE 802.11k
Port mirroring: Yes
Number of VLANs: 4096
Flow control support: Yes
VLAN support: Yes
Virtual LAN features: Voice VLAN
MAC address auto-learning supported: Yes
Cable types supported: Cat3, Cat4, Cat5
Rate limiting: Yes
MAC address auto-aging supported: Yes
IP routing: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
Link aggregation: Yes
Internal memory: 128 MB
Memory type: DDR-SDRAM
Flash memory: 16 MB
Package depth: 290 mm
Package type: Box
Package weight: 3.06 kg
Package height: 85 mm
Package width: 500 mm
IPv4 & IPv6 features: IPv6 Telnet
Console port: RJ-45
SFP module slots quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
Power connector: AC-in jack
Gigabit Ethernet (copper) ports quantity: 24
Packet buffer memory: 0.5 MB
MAC address table: 8192 entries
Switching capacity: 58 Gbit/s
Forwarding rate: 43.152 Mpps
Jumbo frames: 9600
Jumbo frames support: Yes
Multicast support: Yes
Warnings: Ensure the unit is adequately ventilated during operation., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Do not open the case or try to repair it yourself.
Fiber type: Multi-mode
