TP-Link Omada 16-Port 2.5G and 2-Port 10GE SFP+ L2+ Managed Switch with 8-Port PoE+

Form factor: 1U
Product colour: Black
LED indicators: Yes
Rack mounting: Yes
Number of fans: 2 fan(s)
Power source: AC
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (max): 299.4 W
Power supply included: Yes
MAC address filtering: Yes
Security algorithms: HTTPS, SSL/TLS, SSH, SSH-2
DHCP features: DHCP snooping, DHCP server, DHCPv6 snooping, DHCPv6 client, DHCP client, DHCP relay
IGMP snooping: Yes
Static port security: Yes
Authentication: MAC-based authentication, Port-based authentication
SSH/SSL support: Yes
Access Control List (ACL): Yes
Loop protection: Yes
Password protection: Yes
Queue scheduling algorithms: Weighted Round Robin (WRR), SP, WRR+SP
Authentication type: AAA, TACACS+
IP-MAC-Port binding: Yes
BPDU filtering/protection: Yes
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 1021.64 BTU/h
Quality of Service (QoS) support: Yes
Web-based management: Yes
System event log: Yes
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
Switch type: Managed
Switch layer: L2+
Cloud-managed: Yes
Depth: 180 mm
Width: 440 mm
Height: 44 mm
Ethernet LAN data rates: 100,1000,2500 Mbit/s
Networking standards: IEEE 802.1D, IEEE 802.1s, IEEE 802.1w
Flow control support: Yes
VLAN support: Yes
Rate limiting: Yes
Head-of-line (HOL) blocking: Yes
Virtual LAN features: Port-based VLAN, Protocol-based VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Private VLAN
10G support: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Link aggregation: Yes
Port mirroring: Yes
IP routing: Yes
Package type: Box
Quick start guide: Yes
Cables included: AC
Certification: CE, FCC, RoHS
Compliance certificates: Federal Communications Commission (FCC), RoHS
Management protocols: SNMP v1/v2c/v3, SNTP
GARP VLAN Registration Protocol (GVRP): Yes
SFP+ module slots quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 16
Power connector: AC-in jack
Console port: RJ-45/micro-USB
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Static route: Yes
Packet buffer memory: 12 MB
Switching capacity: 120 Gbit/s
Forwarding rate: 89.28 Mpps
MAC address table: 16000 entries
Jumbo frames support: Yes
Number of static routes: 48
Number of IP interfaces: 32
Jumbo frames: 9000
Total Power over Ethernet (PoE) budget: 240 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 8
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Y
Sustainability compliance: Yes
