Gigabyte | H610M S2H V2 1.0 | Processor family Intel | Processor socket LGA1700 | DDR5 DIMM | Supported hard disk drive interfac

Warranty period: 3 year(s)
Processor socket: LGA 1700
Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3
Maximum number of SMP processors: 1
Supported processor sockets: LGA 1700
Processor manufacturer: Intel
Maximum internal memory supported by processor: 96 GB
Graphics card family: Intel
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
Graphics card: HD Graphics
On-board graphics card: Yes
On-board graphics card model: Intel® HD Graphics
Power source type: ATX
PC health monitoring: Fan, LED, Voltage, Water cooling, Temperature
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Cooling type: Active
Audio chip: Realtek ALC897
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Product colour: Black
Motherboard chipset: Intel H610 Express
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory clock speed (max): 5600 MHz
Supported memory clock speeds: 4400 MHz, 4800, 5200, 5600
Unbuffered memory: Yes
ECC сompatibility: ECC & Non-ECC
Supported memory module capacities: 32GB, 8GB, 12GB, 48GB, 1GB, 2GB, 4GB
Maximum internal memory: 96 GB
Height: 35 mm
Width: 230 mm
Depth: 215 mm
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Number of COM connectors: 1
Number of SATA III connectors: 4
12V power connector: Yes
Front panel audio connector: Yes
Serial port headers: 1
USB 2.0 connectors: 2
CPU fan connector: Yes
Number of chassis fan connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
RGB LED pin header: Yes
Front panel connector: Yes
ATX Power connector (24-pin): Yes
TPM connector: Yes
EPS power connector (8-pin): Yes
Clear CMOS jumper: Yes
Clear CMOS button: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Package weight: 690 g
Package width: 265 mm
Package height: 52 mm
Package depth: 235 mm
Bundled software: Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries included: Yes
Cables included: SATA
Number of storage drives supported: 1
Supported storage drive interfaces: M.2, SATA
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
PS/2 ports quantity: 1
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
DisplayPorts quantity: 1
Microphone in: Yes
DVI-D ports quantity: 1
Headphone outputs: 1
Number of M.2 (M) slots: 1
PCI Express x1 slots: 1
PCI Express x16 slots: 1
Battery type: CR2032
Battery weight: 3 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Supported DIMM module capacities: 8GB, 16GB
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Warnings: Before starting any maintenance or installation, disconnect the product from the power supply., Avoid direct contact with electronics to prevent electrostatic damage., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
