Płyta główna Gigabyte H610M S2H V2

Warranty period: 3 year(s)
Processor socket: LGA 1700
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3
Supported processor sockets: LGA 1700
Maximum number of SMP processors: 1
Maximum internal memory supported by processor: 96 GB
Graphics card: HD Graphics
On-board graphics card: Yes
Maximum resolution: 4096 x 2304 pixels
HDCP: Yes
On-board graphics card model: Intel® HD Graphics
Graphics card family: Intel
Power source type: ATX
PC health monitoring: Water cooling, Voltage, Temperature, Fan, LED
Audio chip: Realtek ALC897
Cooling type: Active
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Audio output channels: 7.1 channels
Product colour: Black
Motherboard chipset: Intel H610 Express
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Number of memory slots: 2
ECC сompatibility: ECC & Non-ECC
Supported memory clock speed (max): 5600 MHz
Memory channels: Dual-channel
Unbuffered memory: Yes
Supported memory clock speeds: 5200, 4400, 4800, 5600
Maximum internal memory: 96 GB
Supported memory module capacities: 12GB, 2GB, 4GB, 1GB, 32GB, 8GB, 48GB
Width: 230 mm
Depth: 215 mm
Height: 35 mm
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
12V power connector: Yes
Serial port headers: 1
CPU fan connector: Yes
Front panel connector: Yes
TPM connector: Yes
Number of COM connectors: 1
Number of SATA III connectors: 4
Number of chassis fan connectors: 2
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
RGB LED pin header: Yes
Clear CMOS button: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
Package height: 52 mm
Package width: 265 mm
Package depth: 235 mm
Package weight: 690 g
Bundled software: Norton® Internet Security (OEM version)LAN bandwidth management software
Batteries included: Yes
Cables included: SATA
Number of HDDs supported: 4
Supported storage drive interfaces: M.2, SATA
Supported storage drive types: HDD & SSD
Number of storage drives supported: 1
Headphone outputs: 1
USB 2.0 ports quantity: 4
PS/2 ports quantity: 1
Microphone in: Yes
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
DVI-D ports quantity: 1
DisplayPorts quantity: 1
Number of M.2 (M) slots: 1
PCI Express x1 slots: 1
PCI Express x16 slots: 1
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Battery type: CR2032
Supported DIMM module capacities: 16GB, 8GB
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Warnings: Before starting any maintenance or installation, disconnect the product from the power supply., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal., Avoid direct contact with electronics to prevent electrostatic damage.
