Sapphire PULSE B850M WIFI AMD B850 Socket AM5 micro ATX

Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor socket: Socket AM5
Parallel processing technology support: Not supported
Audio output channels: 5.1 channels
Motherboard form factor: micro ATX
Component for: PC
Motherboard chipset: AMD B850
Product colour: Black
Motherboard chipset family: AMD
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Audio chip: Realtek ALC897
Maximum internal memory: 192 GB
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Maximum internal memory per slot: 48 GB
Supported memory clock speed (max): 7600 MHz
Width: 244 mm
Depth: 235 mm
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
LAN controller: Dragon RTL8125BG
Bluetooth: Yes
Wi-Fi: Yes
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.3
12V power connector: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Serial port headers: 1
Number of chassis fan connectors: 3
USB 2.0 connectors: 2
Front panel audio connector: Yes
RGB LED pin header: Yes
Front panel connector: Yes
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
Number of CPU fan connectors: 1
Number of water pump connectors: 1
Number of RGB LED pin headers: 3
Clear CMOS jumper: Yes
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive types: HDD & SSD
Number of storage drives supported: 6
DisplayPorts quantity: 1
USB connector type: USB Type-A
USB 2.0 ports quantity: 6
Ethernet LAN (RJ-45) ports: 1
Line-in: Yes
Microphone in: Yes
WiFi-AP antenna jack: 2
Headphone outputs: 3
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
PCI Express x4 (Gen 4.x) slots: 1
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
