MSI B850 GAMING PLUS WIFI | Processor family AMD | Processor socket AM5 | DDR5 | Supported hard disk drive interfaces SATA, M.2 Padidinti

MSI B850 GAMING PLUS WIFI

199,52 €

B850 GAMING PLUS WIFI

4711377285438

Galimas pasirinkimas

 3..5 d.d.


Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Maximum internal memory supported by processor: 256 GB
Processor socket: Socket AM5
On-board graphics card: No
Audio chip: Realtek ALC897
Product colour: Black
Motherboard form factor: ATX
Motherboard chipset: AMD B850
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Supported memory types: DDR5-SDRAM
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Supported memory clock speed (max): 8200 MHz
Memory slots type: DIMM
Maximum internal memory: 256 GB
Number of memory slots: 4
Supported memory clock speeds: 4800, 8200, 5600
Depth: 304.8 mm
Width: 243.8 mm
Ethernet LAN: Yes
Bluetooth version: 5.4
Wi-Fi standards: 802.11b, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11g
Wi-Fi: Yes
Ethernet interface type: 5 Gigabit Ethernet
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Total number of SATA connectors: 4
Number of water pump connectors: 1
RGB LED pin header: Yes
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
Number of CPU fan connectors: 4
Number of SATA III connectors: 4
Number of RGB LED pin headers: 3
USB 2.0 connectors: 4
BIOS type: UEFI AMI
RAID levels: 1, 0
Number of storage drives supported: 7
RAID support: Yes
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, Micro SATA III
USB 2.0 ports quantity: 4
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
PCI Express x16 (Gen 3.x) slots: 2
1st M.2 largest key size: 2280
PCI Express x16 (Gen 4.x) slots: 1
3rd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 22110
Number of M.2 (M) slots: 3
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
