LevelOne Access Point WAP8121

Receiver sensitivity: 2.4GHz:802.11n (20MHZ): -70 dBm802.11n (40MHZ): -68 dBm802.11g: -72 dBm802.11b: -95 dBm5GHz:802.11ac (80MHZ): -62 dBm802.11ac (40MHZ): -65 dBm802.11ac (20MHZ): -68 dBm802.11n (40MHZ): -68 dBm802.11n (20MHZ): -70 dBm802.11a: -72 dBm
Modulation: 64-QAM, DSSS, 16-QAM, BPSK, OFDM, DQPSK, QPSK, DBPSK, CCK
Networking standards: IEEE 802.3x, IEEE 802.3af, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u, IEEE 802.11ac, IEEE 802.3, IEEE 802.11a, IEEE 802.11i, IEEE 802.11b
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
Frequency band: 2.4 - 5.825 GHz
2.4 GHz: Yes
Automatic channel selection: Yes
Wi-Fi Multimedia (WMM)/(WME): Yes
Channels quantity: 36 channels
5 GHz: Yes
Maximum data transfer rate: 433 Mbit/s
Quality of Service (QoS) support: Yes
Number of users: 80 user(s)
Flow control support: Yes
Product colour: White
Reset button: Yes
Internal: No
Placement: Ceiling, Wall
LED indicators: WLAN, Power
Output voltage: 12 V
Power consumption (typical): 15 W
Output current: 1.5 A
Power over Ethernet (PoE): Yes
Security algorithms: WPA, 64-bit WEP, WPA2, WPA2-AES, WPA2-PSK, 128-bit WEP, WPA2-TKIP
Number of SSID supported: 8
Service Set Identifier (SSID) features: SSID broadcast on/off
Operating temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): -20 - 50%
Storage relative humidity (H-H): 10 - 90%
Storage temperature (T-T): 5 - 90 °C
Firmware upgradeable: Yes
Web-based management: Yes
Switch type: Managed
Depth: 38.5 mm
Height: 189 mm
Weight: 326 g
Width: 189 mm
Package height: 317 mm
Package weight: 680 g
Package depth: 62 mm
Package width: 214 mm
Cables included: LAN (RJ-45)
Quick start guide: Yes
Ethernet LAN (RJ-45) ports: 2
WAN connection: Wi-Fi, Ethernet (RJ-45)
DC-in jack: Yes
Antenna direction type: Omni-directional
Antennas quantity: 3
Antenna features: Integrated antenna
Antenna gain level (max): 15 dBi
Harmonized System (HS) code: 85176990
