Mainboard Gigabyte B760 GAMING X DDR4 1.0 Padidinti

Mainboard Gigabyte B760 GAMING X DDR4 1.0

117,64 €

4719331850906

Galimas pasirinkimas

 pristatymas 5...7 d.d.


Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3
Processor manufacturer: Intel
Maximum resolution: 4096 x 2304 pixels
HDCP version: 2.3
HDCP: Yes
Parallel processing technology support: Not supported
Audio output channels: 7.1 channels
Power source type: ATX
PC health monitoring: Fan, Water cooling, Voltage, Temperature
Windows operating systems supported: Windows 10, Windows 11
Motherboard chipset family: Intel
Motherboard form factor: ATX
Supported memory clock speeds: 3200 MHz, 2666, 4266, 2133, 3000, 5333 MHz, 3800, 3333, 3400, 3866, 4600, 4500, 3733, 4300, 4400, 5000, 4133, 4000 MHz, 3666, 4800, 4933, 2933, 3600, 3300, 5133, 2400, 4700, 3466
Number of memory slots: 4
Maximum internal memory: 128 GB
Supported memory types: DDR4-SDRAM
Memory slots type: DIMM
Supported memory clock speed (max): 5333 MHz
Unbuffered memory: Yes
Memory channels: Dual-channel
Width: 305 mm
Depth: 244 mm
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
S/PDIF out connector: Yes
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 3
Serial port headers: 1
Number of SATA III connectors: 4
Front panel audio connector: Yes
Front panel connector: Yes
RGB LED pin header: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
CPU fan connector: Yes
TPM connector: Yes
EPS power connector (8-pin): Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
RAID levels: 1, 0, 10, 5
Number of storage drives supported: 6
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Line-in: Yes
Number of USB 3.2 Gen 2 Type-A ports: 1
Microphone in: Yes
HDMI ports quantity: 1
DisplayPorts quantity: 1
USB 2.0 ports quantity: 5
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 3
