GIGABYTE H610M D3W DDR4 Motherboard - Supports 14th Gen. Intel Core CPUs, 5+1+1 phases VRM, up to 3200MHz DDR4, 1xPCIe 3.0 M.2,

GIGABYTE H610M D3W DDR4 Motherboard - Supports 14th Gen. Intel Core CPUs, 5+1+1 phases VRM, up to 3200MHz DDR4, 1xPCIe 3.0 M.2, 1GbE LAN, USB 3.2 Gen 1
Warranty period: 3 year(s)
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Processor manufacturer: Intel
Compatible processor series: Intel Core i7 13th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i3 12th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel® Celeron®, Intel® Pentium®, Intel Core i3 13th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i3 14th Gen, Intel Core i9 14th Gen, Intel Core i9 13th Gen
Parallel processing technology support: Not supported
DirectX version: 12.0
Power source type: ATX
Audio chip: Realtek ALC897
Product colour: Grey
Motherboard chipset: Intel H610
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Component for: PC
PC health monitoring: Voltage, Fan, Temperature, Water cooling
Windows operating systems supported: Windows 11, Windows 10
Audio output channels: 7.1 channels
Supported memory clock speeds: 3200, 2666, 3000, 2133, 2400, 2933
Maximum internal memory: 64 GB
Memory slots type: DIMM
Supported memory clock speed (max): 3200 MHz
Unbuffered memory: Yes
Supported memory types: DDR4-SDRAM
Number of memory slots: 2
Memory channels: Dual-channel
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 32 GB
Depth: 220 mm
Width: 244 mm
Height: 35 mm
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
LAN controller: Realtek RTL8111H
Number of SATA III connectors: 4
USB 2.0 connectors: 1
TPM connector: Yes
Front panel connector: Yes
CPU fan connector: Yes
Number of EPS power connectors (8-pin): 1
Serial port headers: 1
Number of chassis fan connectors: 2
Number of CPU fan connectors: 1
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
BIOS memory size: 128 Mbit
ACPI version: 5.0
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
Package width: 265 mm
Package depth: 265 mm
Package height: 54 mm
Package weight: 800 g
Bundled software: Norton® Internet Security (OEM version) LAN bandwidth management software
Screws included: Yes
Batteries included: Yes
Number of storage drives supported: 5
Supported storage drive interfaces: M.2, SATA III
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
HDMI version: 2.1
Line-in: Yes
Microphone in: Yes
USB 2.0 ports quantity: 4
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 1
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 3.0
Battery type: CR2032
Number of battery cells: 1
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Weight: 770 g
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
