Płyta główna Gigabyte H610M H V3 DDR4

Warranty period: 3 year(s)
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®
Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Maximum resolution: 4096 x 2304 pixels
Parallel processing technology support: Not supported
Graphics card: HD Graphics
Graphics card family: Intel
HDCP: Yes
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset: Intel H610 Express
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
PC health monitoring: Voltage, Temperature, Water cooling, Fan
Cooling type: Active
Motherboard form factor: micro ATX
Power source type: ATX
Product colour: Black
Memory channels: Dual-channel
Number of memory slots: 2
Memory slots type: DIMM
Supported memory clock speed (max): 3200 MHz
Supported memory types: DDR4-SDRAM
Unbuffered memory: Yes
Supported memory module capacities: 8GB, 1GB, 16GB, 2GB, 4GB, 12GB, 32GB
Supported memory clock speeds: 2933, 3200 MHz, 2666, 3000, 2133, 2400
Maximum internal memory: 64 GB
ECC сompatibility: ECC & Non-ECC
Width: 230 mm
Height: 35 mm
Depth: 215 mm
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi: No
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
Front panel connector: Yes
TPM connector: Yes
Number of SATA III connectors: 4
RGB LED pin header: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
CPU fan connector: Yes
Serial port headers: 1
Front panel audio connector: Yes
12V power connector: Yes
Clear CMOS button: Yes
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
Package height: 52 mm
Package width: 265 mm
Package weight: 684 g
Package depth: 235 mm
Bundled software: Norton Internet Security (OEM version) LAN bandwidth management software
Cables included: SATA
Batteries included: Yes
Supported storage drive types: HDD & SSD
Number of HDDs supported: 1
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 5
Headphone outputs: 3
USB connector type: USB Type-A
DVI-D ports quantity: 1
Microphone in: Yes
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
PS/2 ports quantity: 1
Number of M.2 (M) slots: 1
PCI Express x1 slots: 1
PCI Express x16 slots: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Battery weight: 3 g
Battery type: CR2032
Lithium weight per battery: 0.07 g
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Warnings: Avoid direct contact with electronics to prevent electrostatic damage., Before starting any maintenance or installation, disconnect the product from the power supply., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
