FSP | HEXA 85+ PRO 550 | 550 W

Number of fans: 1 fan(s)
Fan diameter: 12 cm
On/off switch: Yes
Product colour: Black
Cooling type: Active
Input current: 7.5 - 3 A
Max output current (+12V): 45.83 A
Combined power (+3.3V): 100 W
Total power: 550 W
AC input frequency: 50 - 60 Hz
Max output current (+5V): 20 A
AC input voltage: 100 - 240 V
Combined power (+5Vsb): 12.5 W
Power Factor Correction (PFC) type: Active
Hold time: 17 ms
Efficiency: 85%
Combined power (-12V): 3.6 W
Power protection features: Over power, Short circuit, Over voltage, Over current
Combined power (+5V): 100 W
Max output current (+3.3V): 20 A
Combined power (+12V): 550 W
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 2.5 A
Height: 86 mm
Weight: 1.33 kg
Depth: 150 mm
Width: 140 mm
Purpose: PC/Server
Bearing technology: Sleeve
80 PLUS certification: 80 PLUS Bronze
ATX version: 2.5
Power supply unit (PSU) form factor: ATX
EPS version: 2.92
Cables included: CPU, PCIe, Peripheral (Molex), SATA
ATX Power connector (24-pin): Yes
Cabling type: Non-Modular
PCI Express power connectors (6+2 pin): 2
Peripheral (Molex) power connectors (4-pin): 2
Floppy disk drive connector: Yes
Motherboard power connector: 24-pin ATX
Number of SATA power connectors: 8
Floppy drive power connector: 1
PCI Express connector: Yes
CPU power connector (4+4 pin): Yes
Harmonized System (HS) code: 84733020
