FSP Power Supply ADVAN 1000 GM 80+G 1000W Fully Modular ATX3.1/GEN5.1 for retail sales

On/off switch: Yes
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Cooling type: Active
Product colour: Black
Efficiency: 90%
Total power: 1000 W
Combined power (+5V): 100 W
Power factor: 0.9
Max output current (+5V): 20 A
Input current: 6 A
Combined power (+5Vsb): 15 W
Max output current (+3.3V): 20 A
Combined power (+12V): 1000 W
Combined power (-12V): 3.6 W
AC input voltage: 100 - 240 V
Combined power (+3.3V): 100 W
Power Factor Correction (PFC) type: Active
Max output current (+5Vsb): 3 A
Max output current (+12V): 83.33 A
Power protection features: Short circuit, Over voltage, Surge & inrush protection (SIP), Over power, No load operation, Under voltage, Over current
Max output current (-12V): 0.3 A
Depth: 140 mm
Width: 150 mm
Height: 86 mm
Purpose: PC
80 PLUS certification: 80 PLUS Gold
ATX version: 3.1
Bearing technology: HYB
Power supply unit (PSU) form factor: ATX
Cabling type: Fully-Modular
CPU power connector (4+4 pin): Yes
Motherboard power cable length: 60 cm
CPU power cable length: 70 cm
Motherboard power connector: 20+4 pin ATX
Number of SATA power connectors: 4
PCI Express power connectors (6+2 pin): 2
Peripheral (Molex) power connectors (4-pin): 4
PCI Express power cable length: 70 cm
PCI Express power connectors (12-pin): 1
