COUGAR Netzteil ATLAS 750W ATX3.1 / 80 Plus Bronze

Cooling type: Active
Product colour: Black
On/off switch: Yes
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Power protection features: Short circuit, Over voltage, Under total voltage, Overheating, Over power, Over current
Max output current (+5V): 22 A
Efficiency: 87%
Max output current (+3.3V): 22 A
Combined power (+5V): 140 W
Combined power (+12V): 750 W
AC input voltage: 100 - 240 V
Input current: 10-6 A
Power Factor Correction (PFC) type: Active
Total power: 750 W
Combined power (+5Vsb): 15 W
AC input frequency: 50/60 Hz
Combined power (-12V): 3.6 W
Max output current (-12V): 0.3 A
Combined power (+3.3V): 140 W
Max output current (+12V): 62.5 A
Max output current (+5Vsb): 3 A
Depth: 150 mm
Weight: 1.94 kg
Width: 140 mm
Height: 86 mm
Power supply unit (PSU) form factor: ATX
Purpose: PC
Bearing technology: Rifle
80 PLUS certification: 80 PLUS Bronze
ATX version: 3.1
Package depth: 158 mm
Package weight: 2.23 kg
Package height: 165 mm
Package width: 187 mm
PCI Express power connectors (12+4 pin): 1
PCI Express power connectors (12+4 pin) cable length: 600 mm
SATA power cable length: 150, 450
Motherboard power cable length: 55 cm
CPU power cable length: 70 cm
CPU power connector (4+4 pin): Yes
Cabling type: Non-Modular
Peripheral (Molex) power connectors (4-pin): 2
PCI Express power connectors (6+2 pin): 4
Number of SATA power connectors: 6
Motherboard power connector: 24-pin ATX
