Chieftec Polaris power supply unit 650 W 20+4 pin ATX PS/2 Black

Fan diameter: 12 cm
Cooling type: Active
Product colour: Black
Fan location: Top
Number of fans: 1 fan(s)
Power protection features: Short circuit, Over voltage, Under voltage, Over current, Overheating, Overload
Max output current (+5V): 22 A
Input current: 10 A
Combined power (+5Vsb): 15 W
AC input voltage: 100 - 240 V
Combined power (+3.3V): 120 W
Max output current (+12V): 54.2 A
Power Factor Correction (PFC) type: Active
AC input frequency: 50 - 60 Hz
Max output current (+3.3V): 22 A
Combined power (+5V): 120 W
Max output current (+5Vsb): 3 A
Total power: 650 W
Combined power (-12V): 3.6 W
Combined power (+12V): 650 W
Max output current (-12V): 0.3 A
Weight: 2.17 kg
Height: 87 mm
Depth: 140 mm
Width: 150 mm
80 PLUS certification: 80 PLUS Gold
Purpose: PC
Power supply unit (PSU) form factor: PS/2
ATX version: 2.4
Package weight: 2.48 kg
Package type: Box
Compliance certificates: RoHS
Floppy disk drive connector: Yes
Cabling type: Fully-Modular
Floppy drive power connector: 1
Motherboard power connector: 20+4 pin ATX
SATA power cable length: 150, 450 mm
PCI Express power connectors (6+2 pin): 4
Number of SATA power connectors: 6
Peripheral (Molex) power connectors (4-pin): 3
Peripheral (Molex) power cable length: 150, 450 mm
Motherboard power cable length: 65 cm
CPU power connector (4+4 pin): Yes
CPU power cable length: 65 cm
PCI Express power cable length: 50 cm
Harmonized System (HS) code: 84733020
