Gigabyte A520 AORUS ELITE motherboard Socket AM4 ATX AMD A520 Padidinti

Gigabyte A520 AORUS ELITE motherboard Socket AM4 ATX AMD A520

85,56 €

4719331809812

Galimas pasirinkimas

 pristatymas 5...7 d.d.


Processor manufacturer: AMD
Compatible processor series: 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen™ 7
Supported processor sockets: Socket AM4
Processor socket: Socket AM4
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
Audio output channels: 7.1 channels
PC health monitoring: Voltage, Temperature, Fan
Audio chip: Realtek ALC1200
Windows operating systems supported: Windows 10 x64
Motherboard chipset family: AMD
Motherboard chipset: AMD A520
Motherboard form factor: ATX
Supported memory clock speeds: 2400, 4000, 3200 MHz, 2667, 4400, 3333, 4600, 2933, 3600, 4733, 2133
Number of memory slots: 4
Memory channels: Dual-channel
Maximum internal memory: 128 GB
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Unbuffered memory: Yes
Depth: 244 mm
Width: 305 mm
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
TPM connector: Yes
CPU fan connector: Yes
EPS power connector (8-pin): Yes
Serial port headers: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 2
RGB LED pin header: Yes
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
Front panel connector: Yes
Power fan connector: Yes
Front panel audio connector: Yes
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
RAID levels: 0, 10, 1
Supported storage drive interfaces: M.2, Serial ATA III
Number of storage drives supported: 5
Headphone outputs: 5
HDMI ports quantity: 1
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
DVI-D ports quantity: 1
PS/2 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
S/PDIF out port: Yes
Number of M.2 (M) slots: 1
PCI Express x1 slots: 3
PCI Express x16 slots: 1
