GIGABYTE H610M K V2 Motherboard - Intel Core 14th CPUs, up to 5600MHz DDR5, 1xPCIe 3.0 M.2, 1GbE LAN, USB 3.2 Gen 1

Warranty period: 3 year(s)
Compatible processor series: Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel® Pentium® Gold, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel® Celeron®, Intel Core i7 13th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i9 14th Gen, Intel Core i3 14th Gen, Intel Core i9 13th Gen
Supported processor sockets: LGA 1700
Processor manufacturer: Intel
Processor socket: LGA 1700
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
DirectX version: 12.0
HDCP: Yes
Motherboard chipset: Intel H610
Power source type: ATX
PC health monitoring: Fan, Water cooling, Voltage, Temperature
Audio output channels: 7.1 channels
Cooling type: Passive
Product colour: Dark brown
Audio chip: Realtek ALC897
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Maximum internal memory per slot: 64 GB
ECC сompatibility: ECC & Non-ECC
Unbuffered memory: Yes
Supported memory clock speeds: 4800, 5600 MHz, 5200, 4400
Maximum internal memory: 128 GB
Memory channels: Dual-channel
Number of memory slots: 2
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 5600 MHz
Width: 226 mm
Height: 35 mm
Depth: 185 mm
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet
Number of CPU fan connectors: 1
Number of EPS power connectors (8-pin): 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel audio connector: Yes
Front panel connector: Yes
CPU fan connector: Yes
TPM connector: Yes
USB 2.0 connectors: 1
EPS power connector (8-pin): Yes
Number of SATA III connectors: 2
ATX Power connector (24-pin): Yes
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
Package width: 265 mm
Package weight: 723 g
Package depth: 235 mm
Package height: 52 mm
Batteries included: Yes
Screws included: Yes
Number of storage drives supported: 3
Supported storage drive interfaces: M.2, PCI Express 3.0, SATA III
Supported storage drive types: HDD & SSD
Number of HDDs supported: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Microphone in: Yes
HDMI ports quantity: 1
DisplayPorts quantity: 1
USB 2.0 ports quantity: 4
DisplayPort version: 1.2
Ethernet LAN (RJ-45) ports: 1
HDMI version: 2.1
Headphone outputs: 1
Line-in: Yes
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 3.0
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Lithium weight per battery: 0.07 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Number of battery cells: 1
Weight: 650 g
Products per shipping (inner) case: 1 pc(s)
