Asus | TUF GAMING A520M-PLUS II | Processor family AMD | Processor socket AM4 | DDR4 DIMM | Memory slots 4 | Supported hard disk

Supported processor sockets: Socket AM4
Compatible processor series: AMD Ryzen 5000 Series, AMD Ryzen 3000 Series
Processor manufacturer: AMD
Processor socket: Socket AM4
Maximum resolution: 3840 x 2160 pixels
Parallel processing technology support: Not supported
Audio chip: Realtek ALC887 / Realtek ALC897
Motherboard chipset: AMD A520
Motherboard chipset family: AMD
Windows operating systems supported: Windows 10 x64
Audio output channels: 7.1 channels
ECC сompatibility: ECC
Supported memory clock speeds: 4600, 2400, 2800, 2133, 4133, 4000, 4800, 3333, 4466, 3600, 3733, 4400, 3466, 3000, 3866, 3200, 2666, 4266
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Memory channels: Dual-channel
Wake-on-LAN ready: Yes
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Number of COM connectors: 1
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of M.2 (M) slots: 1
S/PDIF out connector: Yes
CPU fan connector: Yes
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 2
Front panel audio connector: Yes
USB 2.0 connectors: 2
RGB LED pin header: Yes
12V power connector: Yes
TPM connector: Yes
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Drivers included: Yes
Cables included: SATA
RAID levels: 1, 10, 0
Supported storage drive interfaces: M.2, PCI Express 3.0, SATA III
Supported storage drive types: HDD & SSD
Number of storage drives supported: 5
Number of audio jack connectors: 3
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.2
USB 2.0 ports quantity: 2
USB connector type: USB Type-A
DisplayPorts quantity: 1
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
PS/2 ports quantity: 1
Number of M.2 (M) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 3.x) slots: 1
Warnings: Store away from water and sources of moisture., Avoid direct contact with sensitive electronic components., Dispose of according to local electro-waste regulations.
