Biostar H81MHV3 3.0 H81 Intel® H81 LGA 1150 (Socket H3) micro ATX

Processor socket: LGA 1150 (Socket H3)
Maximum number of SMP processors: 1
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Pentium®, Intel® Core™ i3
DirectX version: 11.1
HDCP: Yes
Windows operating systems supported: Windows 8.1, Windows 8, Windows 10, Windows 7
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Audio output channels: 5.1 channels
Audio chip: Realtek ALC887
Motherboard chipset: Intel® H81
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Supported memory types: DDR3-SDRAM
Memory slots type: DIMM
Number of memory slots: 2
Maximum internal memory: 16 GB
Supported memory clock speeds: 1066, 1333, 1600 MHz
Width: 170 mm
Depth: 190 mm
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
Peripheral (Molex) power connectors (4-pin): 1
Number of SATA II connectors: 2
Front panel audio connector: Yes
CPU fan connector: Yes
Front panel connector: Yes
Number of SATA III connectors: 2
Clear CMOS jumper: Yes
Cables included: SATA
Supported storage drive interfaces: SATA II, SATA III
Headphone outputs: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
PS/2 ports quantity: 2
USB 2.0 ports quantity: 2
VGA (D-Sub) ports quantity: 1
PCI Express x16 (Gen 2.x) slots: 1
PCI Express x1 (Gen 2.x) slots: 1
Warnings: Dispose of used toner cartridges according to local hazardous waste regulations., Do not tamper with the design of the board or its components, this risks damaging the equipment., Do not place on conductive surfaces or in areas of high humidity.
