MSI MAG B760 TOMAHAWK WIFI Processor family Intel Processor socket LGA1700 DDR5 Supported hard disk drive interfaces SATA, M.2 N Padidinti

MSI MAG B760 TOMAHAWK WIFI LGA1700 ATX MB DDR5 2xPCIe x16 4xSATA

178,66 €

MAG B760 TOMAHAWK WIFI

4711377034210

Galimas pasirinkimas

 3..5 d.d.


Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Compatible processor series: Intel® Pentium® Gold, Intel® Celeron®
Maximum number of SMP processors: 1
On-board graphics card: No
Windows operating systems supported: Windows 10, Windows 11
Audio output channels: 7.1 channels
Power source type: ATX
Motherboard chipset family: Intel
Motherboard form factor: ATX
Product colour: Black
Audio chip: Realtek ALC897
Supported memory clock speeds: 6000, 5800, 5000, 6600, 6800, 5600 MHz, 5400, 4800, 5200, 6200, 6400, 7000
Memory slots type: DIMM
Maximum internal memory: 128 GB
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 7000 MHz
Depth: 304.8 mm
Width: 243.8 mm
Wi-Fi standards: 802.11g, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n)
Bluetooth: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Bluetooth version: 5.3
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 2.0 connectors: 4
S/PDIF out connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: Yes
Front panel audio connector: Yes
Number of SATA III connectors: 4
RGB LED pin header: Yes
ATX Power connector (24-pin): Yes
TPM connector: Yes
Front panel connector: Yes
BIOS type: UEFI AMI
RAID levels: 0, 10, 5, 1
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
DisplayPort version: 1.4
HDMI version: 2.1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
PCI Express x16 slots: 2
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 3
